BM-215-NDI monitor provides multiple inputs including:
- High bandwidth NDI® up to 4K;
- 3GSDI input×2; Loop out×1
- NDI® decode to 3GSDI out ×1
- HDMI 2.0 input ×1
NDI® is a registered trademark of Vizrt Group.
Size |
21.5 inches |
Display area |
495.6×292.2mm |
Resolution |
1920×1080 |
Aspect ratio |
16:9 |
Brightness |
400nits |
Contrast |
3000:1 |
Color Gamut |
100% DCI-P3 |
Color depth |
10bit (8+2FRC) |
Eye Protect |
VICO 1.97 |
Viewing angle |
178°(H) /178°(V) |
RJ45 ×1 |
High bandwidth 4K NDI® |
BNC ×2 |
3G/HD/SD-SDI input |
HDMI ×1 |
HDMI 2.0 input |
RS485 ×1 |
TSL 3.1/4.0 UMD input |
RS485 ×1 |
GPI (Tally) input |
BNC ×1 |
3G/HD/SD-SDI loop output |
BNC×1 |
NDI® decoded to SDI output |
RS485 ×1 |
TSL 3.1/4.0 UMD output |
Analog audio |
3.5mm headphone and speaker |
NDI® |
4096×2160p (30 / 29.97 / 25 / 24 / 23.98) |
3840×2160p (30 / 29.97 / 25 / 24 / 23.98) | |
2048×1080p (60 / 59.94 / 50 / 30 / 29.97 / 25 / 24 / 23.98) | |
2048×1080i (50 / 59.94 / 60) | |
1080p (60 / 59.94 / 50 / 30 / 29.97 / 25 / 24 / 23.98) | |
1080i (60 / 59.94 / 50) | |
720p (60 / 59.94 / 50) | |
NDI® decoded to SDI out |
2048×1080p (60 / 59.94 / 50 / 30 / 29.97 / 25 / 24 / 23.98) |
2048×1080i (50 / 59.94 / 60) | |
1080p (60 / 59.94 / 50 / 30 / 29.97 / 25 / 24 / 23.98) | |
1080i (60 / 59.94 / 50) | |
720p (60 / 59.94 / 50) | |
SDI IN1/2 and LOOP |
2048×1080p (60 / 59.94 / 50 / 30 / 29.97 / 25 / 24 / 23.98) |
2048×1080i (50 / 59.94 / 60) | |
1080p (60 / 59.94 / 50 / 30 / 29.97 / 25 / 24 / 23.98) | |
1080i (60 / 59.94 / 50) | |
1080psf (30 / 29.97 / 25 / 24 / 23.98) | |
720p (60 / 59.94 / 50) | |
480i (59.94), 576i (50) | |
HDMI IN |
4096×2160p (60 / 59.94 / 50 / 30 / 29.97 / 25 / 24 / 23.98) |
3840×2160p (60 / 59.94 / 50 / 30 / 29.97 / 25 / 24 / 23.98) | |
1080p (60 / 59.94 / 50 / 30 / 29.97 / 25 / 24 / 23.98) | |
1080i (60 / 59.94 / 50) | |
720p (60 / 59.94 / 50) |
Input voltage |
DC 12V-17V, AC 100-240V, 50/60Hz |
Power consumption |
45W |
Working temperature |
0°C~+50°C |
Working humidity |
10%~90% |
Storage temperature |
-15°C~+60°C |
Storage humidity |
10%~90% |
Dimensions |
530.6×364.3×74.2mm |
Net weight (main body) |
Net 5.90kg; With package 10.05kg |
