SWIT S-3812S | 2ch x 6A Top Fast Simultaneous Charger & Adaptor
649.00 CHF701.55 CHF inkl. 8.1% MwSt
SWIT S-3812S | 2ch x 6A Top Fast Simultaneous Charger & Adaptor 2ch x 6A Top Fast Simultaneous Charger & Adaptor:◆SWIT Exclusive Quality◆Auto identify battery type and charging method◆6A fast charging for SWIT typical batteries; 3A for others;◆Support AC to XLR or Batteries to XLR output;◆max stable output 200W/12A; LCD display detailed info
Artikel-Nr.
719.S-3812S
Garantiezeit
24 Monate
Verfügbarkeit
Nicht an Lager (Lieferbar in 5-10 Tagen)
Dual-channel Fast Charger
SWIT S-3812S V-mount, Simultanes 2 Kanal Schnellladegerät (190Wh Akku D-8161S wird in 2h 55min anstatt 7h 40min geladen) mit LCD Anzeige und grossen LED Indikatoren. Erkennt Batterietyp und wählt entsprechenden Ladevorgang. 6A Schnellladung für entsprechende Switbatterien oder 3A Ladestrom für andere Akkus. XLR-4 Output.
Max charging current: 6A
S-3812S can charge 2 V-mount batteries simultaneously at Max 6A fast charging current, to SWIT particular batteries. The charging speed is quite faster than normal chargers.
The following battery models support 6A fast charging:
S-8340S, S-8360S, D-8161S
And for other batteries, the charging current is 3A.
Charging time comparation
| Battery model |
S-8340S
|
S-8360S
|
D-8161S
|
S-8110S
|
S-8160S
|
S-8180S
|
| Capacity |
160Wh
|
250Wh
|
190Wh
|
130Wh
|
190Wh
|
220Wh
|
| Normal charging time |
6h 20m
|
9h 30m
|
7h 40m
|
4h 45m
|
7h 40m
|
8h 30h
|
| S-3812S charging time |
2h 35m
|
3h 50m
|
2h 55m
|
3h 25m
|
5h 05m
|
5h 55m
|
AC-DC Adapting Output
S-3812S supports 1-ch AC-DC adapting output via 4-pin XLR port. By S-7102 (4-pin XLR female to male) cable, it can supply 16.8V DC power to the other equipments, Max load 200W/12A.
When adapting load is less than 100W, S-3812S can still charge battery simultaneously. (2 batteriessequential)
Remark: S-7102 cable is optional purchased.
Battery-DC Adapting Output
You can also mount batteries onto S-3812S, and output DC power via 4-pin XLR port. By S-7102 (4-pin XLR female to male) cable, it can supply 16.8V DC power to the other equipments, Max load 200W/12A.
Remark: S-7102 cable is optional purchased.
LCD Charging Info Display
S-3812S has an LCD screen to display the real time charging/adapting information, includes:
Battery Charging/Discharging status
Real time capacity and percentage
Real time Voltage/Current
Remaining time to fully charged
Remaining time to fully discharged
Battery cycle times
Adapting output current and power
Remark: The battery info display only available with SWIT digital Li-ion batteries: S-8320S; S-8340S; S-8360S; D-8161S/R. For other non-digital batteries, the charger will only display real time voltage and current.
3-color LED Indicators
S-3812S has the 3-color LED indicators for both 2 channels:
Red light slowly flashes: The battery is charging
Red light fast flashes: The battery is about to fully charged
Green light constant: The battery is fully charged
Green light flashes: The battery is adapting output
Orange light flashes: Battery or Charger abnormal alert
6A Fast Charger
The normal chargers offer 2A charging current, while SWIT S-3812 can supply 6A charging current, which saves charging time effectively.
Take SWIT S-8340 (160Wh) battery for example: by normal charger it takes 6 hours and 20 minutes to fully charge, and by S-3812 fast charger, the 160Wh battery can be charged to 80% capacity within 1 hour 30 minutes, and 100% fully charged within 2 hour and 35 minutes.
Battery-DC Adapting Output
S-3812 adaptor function support AC to 4-pin XLR DC output, and Battery to 4-pin XLR DC output.
For battery to DC adapting output, the adapting load is determined by the batteries mounted.
When only 1 battery is mounted, the 4-pin XLR output load follows Max load of the battery;
When 2 batteries are mounted, the 4-pin XLR load can be the sum of the 2 batteries (Max 200W).
It is suggested that use 2 same model batteries with similar cycle times, to maximum the power load.
Multiple Safety Protection Design
SWIT charger can identify different chemical types of batteries, and provide the correct charging program, to protect the batteries from over current, over charging, high temperature, etc.
