Tentacle SYNC E mkII - Standard

Das Tentacle Sync E Standard Set ist eine komplette Hardware-/Softwarelösung, die dir einen einfachen und kostengünstigen Start in die Timecode-Synchronisation ermöglicht. Es besteht aus zwei sehr kleinen und benutzerfreundlichen Timecode-Generatoren, welche an fast jede Kamera oder Audio-Rekorder angeschlossen werden können. Ebenfalls im Set enthalten ist eine leistungsstarke Sync-Software für OS X. Tentacle Sync hilft somit Ihren Workflow von Produktion bis Postproduktion erheblich zu beschleunigen.

Now it comes with Bluetooth Low Energy, which makes the setup even easier and allows you to monitor all boxes on your mobile device.The Tentacle Setup App can tell you with frame accuracy how well your boxes are syncing. It will allow you to connect Tentacles to nearly any kind of camera or audio recorder. From a DSLR to an ARRI Alexa, Tentacle will do the job. The 3.5mm mini jack is without a doubt the most common and versatile connector in the world. And with our new clamp it’s now become lockable, meaning you don’t need to buy any non-standard, unusual cables or connectors.

FEATURES

• Super Small and Lightweight
• Easy Setup and Monitoring via Bluetooth 4.2 (Low Energy)
• Generates and accept any SMPTE Timecode Rates
• Two Tentacle Sync Studio Software Licenses Included
• Included Tentacle Clamp locks a Right-Angle Mini Jack Connector
• Improved Built-In Reference Microphone
• Designed and Made With Love in Cologne, Germany

SPECS

LTC Timecode:      According to SMPTE-12M Standard
Drift:                        High Precision TCXO: Accuracy Less than 1 Frame Drift in 24 Hours (-30°C to +85°C)
Frame rates:           23.98, 24, 25, 29.97, 29.97DF, 30
Timecode I/O:        Mini Jack Socket
Audio:                     Built-In Reference Mic
Power:                    Built-In Lithium Polymer Battery, up to 35 hrs Operating Time, Fast Charging via USB-C (max. 1.5 hrs)
Mounting:               Integrated Hook Surface on the Back for Easy Mounting
Weight:                   30 g / 1 oz
Dimensions:           38 x 50 x 15 mm / 1.49 x 1.97 x 0.59 inches

WHAT’S IN THE BOX?

2x   Tentacle Sync E – Timecode Generators

2x   Mini-Jack-Cables (90° angled) for syncing or connecting to cameras with TRS input like 5D, BMPCC, GH4 …

2x   USB-C Cables for Charging and Setup (Win/Mac)

2x   Tentacle Clamps for Locking your Right-Angle Cables to the Tentacle SYNC E

10x Velcro Loop Pads for Mounting the Tentacle to any Device

4x   Coloured Rubber Bands

1x    Quickstart Guide
